Web Guiding System

• Capacity
• Up to 400 m/min web speed

• Color
• All color available

• Diameter
• Roll Stand Diameter up to 1200 mm

• Dimension (L*W*H)
• Customize Centimeter (cm)

• Drive Type
• Integrated Motorized Drive

• Features
• Automatic Web Alignment, Control Panel, Low Maintenance, Fast Response

• Lubricating System
• Self-Lubricated Bearings

• Motor Power
• Stepper or Servo Motor, 50W - 150W

• Noise Level
• Below 60 dB

• Power
• 240-+ Watt (w)

• Power Source
• Other, Electric/Automation Control

• Product Type
• Machine Accessories

• Shape
• Rectangular Unit

• Size
• Standard/Custom sizes from 100 mm to 2500 mm

• Surface Finish
• Smooth/Glossy

• Surface Treatment
• Other, Powder Coated / Anodized

• Technology
• Other, Electro-Mechanical Web Guiding

• Usage & Applications
• Roll-to-Roll Printing, Lamination, Slitting, Coating and Converting Industries

• Voltage
• 110-240 Volt (v)

• Weight
• 45 Kg - 120 Kg

• Capacity
• Up to 800 mm Web Width

• Color
• All color available

• Diameter
• Unwind Roll: up to 1000 mm

• Dimension (L*W*H)
• Customize Centimeter (cm)

• Drive Type
• AC Motor with Frequency Drive

• Features
• Auto Web Alignment, Digital Display, Heavy Duty Rollers, Easy Roll Change

• Lubricating System
• Manual/Automatic (Optional)

• Motor Power
• 0.5 - 2 HP (as per Design)

• Noise Level
• < 70 dB

• Power
• 600 W

• Power Source
• Other, Electric

• Pressure
• 0.4 - 0.6 MPa (For Pneumatic Tensioners)

• Product Type
• Machine Parts

• Shape
• Rectangular Frame with Roller Assemblies

• Size
• Customizable as per Requirement

• Surface Finish
• Smooth, Anti-corrosive

• Surface Treatment
• Other, Powder Coated / Galvanized

• Technology
• Other, Microprocessor-based Web Guiding System

• Usage & Applications
• Paper, Film, Foil, Textile, and Non-woven Web Unwinding

• Voltage
• 24-240 Volt (v)

• Weight
• Approx. 600 Kg

• Capacity
• Supports wide web width range

• Color
• All color available

• Dimension (L*W*H)
• Customize Centimeter (cm)

• Drive Type
• Electrical Drive

• Features
• User friendly front panel, short circuit protection, accurate error detection, dual display for position and error, durable construction

• Motor Power
• Compatible up to 90W actuator motor

• Noise Level
• < 40 dB

• Power
• 45W

• Power Source
• Other, Electric

• Product Type
• Machine Parts

• Shape
• Rectangular

• Size
• Standard Compact

• Surface Finish
• Matte / Gloss Finish

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Microcontroller Based Automation

• Usage & Applications
• Web guiding for slitting, coating, printing, and converting machinery

• Voltage
• 24-240 Volt (v)

• Weight
• 3.5 kg (approx.)

• Capacity
• Suitable for web width up to 3000 mm

• Color
• All color available

• Diameter
• Applicable sensor diameter: 8 mm - 12 mm

• Dimension (L*W*H)
• Customize Centimeter (cm)

• Drive Type
• Electro-pneumatic drive

• Features
• High accuracy web guiding, user-friendly control panel, fast response, robust hydraulic-pneumatic operation

• Lubricating System
• Self-lubricating components

• Motor Power
• 0.25 HP - 0.5 HP (if equipped)

• Noise Level
• Less than 65 dB

• Power
• 24V DC or 220V AC, depending on model

• Power Source
• Other, Pneumatic / Hydraulic

• Pressure
• 3-7 bar (Pneumatic operating pressure)

• Product Type
• Machine Parts

• Shape
• Rectangular Controller Unit

• Size
• Standard, customizable on request

• Surface Finish
• Matte / Glossy

• Surface Treatment
• Other, Powder Coated / Anodized

• Technology
• Other, Advanced sensor-based control with hydraulic-pneumatic integration

• Usage & Applications
• Used for precise edge guiding and alignment in printing, packaging, and textile industries

• Voltage
• 110-240 Volt (v)

• Weight
• 8-12 kg (approx.)

• Capacity
• Up to 50 kg web tension

• Color
• All color available

• Dimension (L*W*H)
• Customize Centimeter (cm)

• Drive Type
• Electric Drive

• Features
• Digital display, auto/manual modes, easy setpoint adjustment, over-tension protection, user-friendly operation

• Motor Power
• Compatible with various drive motors

• Noise Level
• Low

• Power
• 40 W

• Power Source
• Other, Electric

• Product Type
• Machine Parts

• Shape
• Rectangular

• Size
• Standard

• Surface Finish
• Matte

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Microprocessor Based

• Usage & Applications
• For maintaining constant web tension in printing, laminating, coating, slitting, and packaging machines

• Voltage
• 110-240 Volt (v)

• Weight
• 2.7 kg

• Capacity
• Up to 5kW Tracking Capacity

• Color
• Blue & Silver

• Diameter
• Main shaft: 75 mm approx.

• Dimension (L*W*H)
• Customizable as per project

• Drive Type
• Gear Drive Motorized

• Features
• Corrosion Resistant, Heavy Duty, Precision Tracking, Low Maintenance

• Lubricating System
• Self-Lubricating Joints

• Material
• Mild Steel

• Motor Power
• 1 HP

• Noise Level
• < 65 dB

• Power
• 1 kW

• Power Source
• Other, Electric

• Product Type
• Other, Pivote Tracker System

• Shape
• Rectangular Framing Structure

• Size
• Standard / Customizable

• Surface Finish
• Smooth Coating

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Automatic

• Usage & Applications
• Solar Panel Mounting & Tracking

• Voltage
• 220-240 V AC

• Weight
• Approx. 350 kg

• Capacity
• Handles web width up to 3000 mm

• Color
• Blue-Grey

• Diameter
• Roll Diameter: 76 mm or as required

• Dimension (L*W*H)
• Custom as per application

• Drive Type
• Belt Drive

• Features
• Easy installation, Precise web control, Robust construction, High sensitivity

• Lubricating System
• Maintenance-free sealed bearing

• Material
• Mild Steel (MS)

• Motor Power
• 0.25 HP AC Synchronous Motor

• Noise Level
• Below 70 dB

• Power
• 0.25 HP

• Power Source
• Other, Electric

• Pressure
• Ambient

• Product Type
• Other, Web Guide System

• Shape
• Rectangular with Mounted Roll

• Size
• Custom sizes available

• Surface Finish
• Smooth

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Automatic Sensor Controlled

• Usage & Applications
• Web Alignment for Printing, Packaging, Laminating & Slitting Machines

• Voltage
• 220-240 V AC

• Weight
• Approx. 25-60 kg (varies with size)

• Capacity
• Handles Web Widths from 100mm to 2500mm

• Color
• Silver/Grey with Black Components

• Diameter
• Roller Diameter 50mm to 120mm (for guiding rollers)

• Dimension (L*W*H)
• Customized as per model, e.g. 350mm x 180mm x 120mm

• Drive Type
• Servo/Stepper Motor

• Features
• High Precision, Easy Installation, User-Friendly Interface, Maintenance Free

• Lubricating System
• Self-lubricating Components

• Material
• Mild Steel, Aluminum Alloy

• Motor Power
• 60W or as per Model

• Noise Level
• <60 dB

• Power
• 45W - 250W

• Power Source
• Other, Electric

• Pressure
• Pneumatic, 3-7 bar (if applicable)

• Product Type
• Other, Edge Guide System

• Shape
• Rectangular Mainframe

• Size
• Standard & Customized Sizes

• Surface Finish
• Anodized/Polished

• Surface Treatment
• Other, Powder Coated

• Technology
• Other, Automatic Sensor-Based

• Usage & Applications
• Web guiding in printing, packaging, textile, paper, and converting industries

• Voltage
• 220V AC

• Weight
• 12-30kg depending on model

• Capacity
• Suitable for web widths from 300mm to 2500mm Milliliter (ML)

• Color
• Blue and Metallic Grey

• Diameter
• Roller Diameter: 50mm to 150mm Millimeter (mm)

• Dimension (L*W*H)
• Varies as per Model (Standard: 900 mm x 350 mm x 260 mm) Millimeter (mm)

• Drive Type
• Direct Drive/Servo Motor

• Features
• High Precision Sensors, Digital Controller, Fast Response Time, Low Maintenance, Energy Efficient

• Lubricating System
• Self-Lubricated Bearings

• Material
• Mild Steel, Aluminum

• Motor Power
• 40W to 90W AC/DC Motor Watt (W)

• Noise Level
• Less than 60 dB db

• Power
• 200W - 500W Watt (w)

• Power Source
• Other, Electric

• Product Type
• Other, Industrial Web Guiding System

• Shape
• Rectangular Base with Cylindrical Rollers

• Size
• Customizable as per requirements

• Surface Finish
• Matte/Smooth

• Surface Treatment
• Other, Powder Coated/Painted

• Technology
• Other, Electromechanical

• Usage & Applications
• For Automatic Guiding of Webs in Printing, Lamination, Slitting, Textile, and Packaging Industries

• Voltage
• 220V AC / 50Hz Volt (v)

• Weight
• Approx. 40-80 kg (varies by configuration) Kilograms (kg)
